PIPELINE APPLICATION PRODUCT

From fabrication to maintenance, AquaTerra delivers complete, end-to-end pipeline solutions backed by a comprehensive range of products—ensuring reliability and performance at every stage.

Pipe Hook

IPPH Pipe Hook

IPPH

IPPHI

IPPH w / IPPHI

Features

Crosby MAGNEX™ Lifting Magnets provide a fast and efficient method for lifting plates and round steel or any similarly shaped fabrications.

IPPHI

IPPHI Replaceable nylon (pa6) inserts for use with the IPPH Pipe Hook that minimises thread and pipe damage.

IPPH w / IPPHI

Available in capacities of 2 through 10 metric tons
Grip Opening (in): 2.06” – 6.06”.
All sizes are RFID equipped.

Lifting Magnet

MAGNEX™ Lifting Magnet

Features

Crosby MAGNEX™ Lifting Magnets provide a fast and efficient method for lifting plates and round steel or any similarly shaped fabrications.
Flat material Capacities 150 kg (331 lbs) to 2000 kg (4409 lbs)
Load thickness from 2 mm (0.08”) to 80 mm (3.15”)
Round material Capacities : 75 kg (166 lbs) to 2205 kg (4409 lbs)
Load Diameter from 50 mm (2”) to 350 mm (13.8”)
All sizes are RFID equipped.

Straub Coupling

Straub Grip-L Axial Restraint Pipe Couplings

Applications

Suitable for pipes within the lower pressure range. Applications include, but are not limited to: ship building, water and waste water treatment plants, and industrial process pipe work
Joins like or dissimilar pipe materials: steel, galvanised, painted, stainless steel, thin-wall stainless steel, PVC, copper

Features

Requires no special tools or pipe-end preparation; only a torque wrench is required for a secure and safe pipe connection that seldom needs retightening
Accommodates up to 5° of pipe misalignment
Vary gap between pipe ends
Absorbs vibration, water hammer, and sound
Special patented grip ring for superior holding power on hard-surfaced pipes
5-year limited warranty
Reusable

Materials

Casing: AISI 316Ti; screws: AISI 316 L; bolts: AISI 316 Ti; anchoring ring: AISI 301; sealing sleeve: EPDM standard

Specifications

EPDM sealing sleeve temperature range: -4°F to 212°F (-20°C to 100°C)
Maximum temperature limit is 212°F (100°C) with EPDM gasket Material. Higher temperature limits may be allowed subject to specific factory approval.

Approvals

National Sanitation Foundation (NSF)
Built to ASTM 1476, Type 2, Class 2 specifications

Straub Open-Flex 1L Couplings

Applications

Suitable for repairing or joining pipes where access to the pipe end is difficult or impossible

Features

Wrap-around design differs from similar type repair products because the installation or
repair is permanent due to the unique flexible lip seal gasket design
Joins like or dissimilar pipe materials: steel, galvanised, painted, stainless steel, thin-wall
stainless steel, PVC, copper
Requires no special tools or pipe-end preparation; only a torque wrench is required for a
secure and safe pipe connection that seldom needs retightening
Accommodates up to 5° of pipe misalignment
Vary gap between pipe ends
Absorbs vibration, water hammer, and sound
Acts as an expansion joint; will accept up to .25" of axial movement
5-year limited warranty
Reusable

Materials

Casing: AISI 316Ti; screws: AISI 4135 steel; bolts: AISI 12L 14 galvanised

Specifications

EPDM sealing sleeve temperature range: - 4°F to 212°F (-20°C to 100°C) Maximum temperature limit is 212°F (100°C) with EPDM gasket Material. Higher temperature limits may be allowed subject to specific factory approval.

Approvals

National Sanitation Foundation (NSF)
Conforms to ASTM 1476, Type 2, Class 3 specifications

Victaulic Coupling

Standard Couplings - Series-S, Style 11

Applications

Designed for a wide range of applications including commercial/industrial construction, mining, and process piping

Features

Housing design allows for optimum strength without excessive casting weight
Comparable to Victaulic's #77 and Grinnell's #7001

Materials

Ductile iron body with rust-inhibiting paint

Approvals

UL listed and Factory Mutual approved

Lightweight Flexible Couplings - Series-L, Style 10

Applications

Designed for applications requiring moderate internal pressure or where weight is a factor such as general purpose, mining, irrigation, and compressed air where a deflection of 5% or less is required

Features

Comparable to Victaulic's #75 and Grinnell's #7000

Materials

•Ductile iron body with rust-inhibiting paint

Approvals

UL listed and Factory Mutual approved

Mechanical Tees - Series-T

Applications

Provides a fast easy way to install a threaded connection along a length of pipe; after drilling or cutting a hole in the pipe at the location of the branch connection, simply attach the clamps around the pipe for a leak-free threaded outlet connection; see chart below for drilling hole specifications

Features

Comparable to Victaulic’s #920 and Grinnell's #7045

Materials

Ductile iron body with rust-inhibiting paint

Approvals

UL listed and Factory Mutual approved

Cylinders

Pumps

Bolt Tensioner

Nut Splitter

Flange Spreader

Puller Kit

Pipe Wrenches & Tongs

Straight Pipe Wrenches Heavy-Duty

Size: 6" to 60“ (150 mm to 1500 mm)

Pipe Capacity

3/4" thru 8" (20 mm to 200 mm)

End Pipe Wrenches Heavy-Duty

Size: 6" to 36“ (150 mm to 900 mm)

Pipe Capacity

13/4" thru 5"(20 mm to 125 mm)

Straight Pipe Wrenches Aluminum

Size: 10" to 48" (250mm to 1200mm)

Pipe Capacity

1/2" thru 6" (40 mm to 150 mm)

RapidGrip Wrenches Heavy-Duty

Size : 10" to 14" (250 mm to 350 mm)

Pipe Capacity

1-1/2" thru 2" (40 mm to 50 mm)

End Pipe Wrenches Aluminum

Size: 10" to 24" (250mm to 600 mm)

Pipe Capacity

1-1/2" thru 3"(40 mm to 80 mm)

Offset Pipe Wrench Heavy-Duty

Size : 14" to 24" (350 mm to 600 mm)

Pipe Capacity

2" to 3" (50 mm to 80 mm)

Chain Wrenches

Compound Leverage Wrenches

C-12 to C-36

Pipe Capacity

4" thru 7-1/2"(100 mm to 185 mm)

S-2 to S-8A

Pipe Capacity

2" to 8" (50 mm to 200 mm)

Chain Tongs (Double-End)

Size : 27 to 64" (686 mm to 1625 mm)

Pipe Capacity

1/4" to 12" (6 mm to 300 mm)

RapidGrip Wrenches Aluminum

Size: 14" to 18" (350 mm to 450 mm)

Pipe Capacity

2" thru 3"(50 mm to 80 mm)

Offset Pipe Wrenches Aluminum

Size: 14" to 24" (350 mm to 600 mm)

Pipe Capacity

2" to 3" (50 mm to 80 mm)

Chain Tongs (Single-End)

Size: 87" (2209 mm)

Pipe Capacity

4" to 18" (100 mm to 450 mm)

Pipe Vises & Support

Portable TRISTAND Vises Yoke/Chain

40-A / 425 / 460-6 / 460-12

1/8” to 12” (3 to 300 mm)

Bench Chain Vise Bottom/Top

Bench Yoke Vise

Portable Chain & Yoke Vise

BC210 to BC810 / BC2A to BC4A

Model 21 to 27

1/8” to 8” (6 to 200 mm)

1/8” to 6” (3 to 150 mm)

Model 39 / 640

1/8” to 5” (3 to 125 mm)

Flange Pipe Welding Vise

Model 464

2-1/2” to 8” (65 to 200 mm)

V Head Pipe Stand

VJ-98 / VJ-99 / VF-99

Height Adjustment

20 to 53" (51 to 132 cm)

Capacity: 12" (300 mm)

2500 lbs (1134 kg)

Angle Pipe Welding Vise

Model 462

1/2” to 12” (15 to 200 mm)

Roller Head Pipe Stand

RJ-98 / RJ-99

Height Adjustment

24 to 55" (61 to 122 cm)

Capacity: 12" (300 mm)

1000 lbs (454 kg)

Straight Welding Vise

Elbow Welding Vise

Model 461

Model 463

1/2” to 8” (15 to 200 mm)

2-1/2” to 8” (65 to 200 mm)

Conveyor Head Pipe Stand

CJ-99

Large Diameter Pipe Stand

RJ-624

Height Adjustment

24 to 55" (76 to 117 cm)

Height Adjustment

16 to 31" (41 to 79 cm)

Capacity: 12" (300 mm)

1000 lbs (454 kg)

Capacity: 12" (300 mm)

4500 lbs (2041 kg)

Pipe Cutting, Preparation & Bending

Heavy Duty (2-A to 6-S)

Steel / Stainless Steel / Heavy-Wall Steel

1/8” to 6” (3 to 150 mm)

4- Wheel (42-A to 44-S)

Steel / Stainless Steel / Heavy-Wall Steel

3/4” to 4” (20 to 100 mm)

Wide-Roll (202)

Steel / Stainless Steel / Heavy-Wall Steel

1/8” to 2” (30 to 50 mm)

Hinged (424 to 472)

Steel / Stainless Steel / Heavy-Wall Steel

2” to 12” (50 to 300 mm)

Hole Cutting Tools HC-300 / HC-450

115V / 230V Pipe Mounting up to 8"

Hole Cutting Capacity:

3" / 4-3/4" (Sch 10, 40 80 Pipe)

Power Pipe Cutter 258/ 258XL

700 Power Drive

Manual Threader Set

2-1/2" to 8" Sch 10/40 Steel Pipe

8" to 12" Sch 10/40 Steel Pipe

Capacity"1/8" to 2" Pipe

(Use with 12-R Die Head)

00-R / 12-R

NPT / NPSM / BSPT

Use with 700 Power Drive

Optional Square Adapter

12-R can be use with 700 Power Drive

Hydraulic Pipe Bender

915

HB-382 / HB-383

1-1/4" TO 12" Sch 10 Steel & SS

1" to 8" K,L,MDWV Copper

3/8" to 2" / 3"

1-1/4" to 6" Sch 40 PVC

1-1/2", 2-1/2" to 3" Sch 80 PVC

918FE

300 Power Drive Complete

1" to 12" Sch 10 Steel, SS

1" to 8" Sch 40 Steel, PVC

115V / 230V

NPT / BSPT

2" to 6" Copper (K,L,MDWV)

2-1/2" to 4" Sch 80 PVC

Pipe Capacity: 1/8" to 2"

Pipe Threading Machine & Stand

300 COMPACT

1233

115V / 230V / NPT / BSPT

Pipe Capacity: 1/8" to 2"

Bolt: 1/4" to 2" (6 to 50mm)

115V / 230V / NPT / BSPT

Pipe Capacity: 1/4" to 3"

Bolt: 10 to 52mm

Universal Leg & Tray Stand 100A

Universal Wheel & Tray Stand 150A

535

115V / 230V / NPT / BSPT

Pipe Capacity: 1/8" to 2"

Bolt: 1/4" to 2" (6 to 50mm)

Universal Wheel & Cabinet Stand 200A

1224

115V / 230V / NPT / BSPT

Pipe Capacity: 1/4" to 4"

Bolt: 1/4" to 2" (6 to 50mm)

Folding Stand 250

Special Wrench

Hex Wrenches (Offset)

Hex Wrenches (Straight)

Size: 9-1/2" (240 mm)

Hex Nut Capacity

1-1/8" to 2-5/8" (29 mm to 67 mm)

Size: 14-1/2" to 20" (362 mm to 500mm)

Hex Nut Capacity

5/8" to 2" (16 mm to 50 mm)

One Stop Wrench

Faucet & Sink Installer

Model 2002 (2 in 1)

The One Tool for Common Faucet

Hex Nut Capacity

3/8", 9/16", 15/16"

Supply Lines and Clamp Nuts

5/8", 3/4", 7/8" 1"

Manual / Power Auger

Model

K-1

K-3 / K-6DH

K-6P / K-6P-XL (Interchange Head)

Application

Removing blockage from Urinal,

Toilet Bowl & Shower Drains

Removing blockage from Urinal,

Toilet Bowl & Shower Drains

Removing blockage from Urinal,

Toilet Bowl & Shower Drains

Pipe / Drain Size

Cable Length

Operatiobns

Up to 2' (50 mm)

4 FT (1.2 M)

3 FT (1.0 M) / 6 FT (2.0 M)

6 FT (2.0 M)

Manual / Drill Powered

Manual

Manual / Drill Powered

Hand / Power Spinner

Model

Application

Pipe / Drain Size

K-25-BP /K-25-DH

Clearing blockages form small drain lines in showers, sinks & tubs

1/2" to 1-1/2" (12.6 mm to 40 mm)

K-26

Clearing blockages form small drain lines in showers, sinks & tubs

3/4" to 1-1/2" (19 mm to 40 mm)

Kwik-Spin

Clearing blockages form small drain lines in showers, sinks & tubs

1/2" to 1-1/2" (12.6 mm to 40 mm)

Power-Spin

Clearing blockages form small drain lines in showers, sinks & tubs

1/2" to 1-1/2" (12.6 mm to 40 mm)

Cable Length

25 FT

Operations

Manual

Manual 2-Way Autofeed

Manual / Drill Powered with Autofeed

Sink Machine

Model

Application

Pipe / Drain Size

PowerClear

K-45

K-40

Opens clogged lavatory, sink lines, urinals, tub & shower drains

3/4" to 1-1/2" (20 mm to 38 mm)

3/4" to 2-1/2" (20 mm to 75 mm)

Drum Machine

Model

Application Chart

Pipe / Drain Size

Speed

Hose power

Motor

Cable Diameter

Available Length

Cable Type

Model

Application Chart

Pipe / Drain Size

Speed

Hose power

Motor

Cable Diameter

Available Length

Cable Type

K-400

SINK LINES / FLOOR / SECONDARY DRAINS

1-1/2" to 4" (38 mm to 102 mm)

170 RPM

1/3 HP

Induction

3⁄8" or 1⁄2" Cable (10 or 13 mm)

50' - 75' - 100' (15 m - 23 m - 30 m)

Integral Wound (IW)

K-750

LATERALS & MAIN LINES

3" to 8" (76 mm to 206 mm)

200 RPM

1/2 HP

Induction

5⁄8" or 3/4" Cable (16 or 19 mm)

25' - 50' - 75' - 100' (7.6 m - 15 m - 23 m - 30 m)

Heavy-Duty Inner Core (HD),
Inner Core (IC), Hollow Core (HC)

K-3800

SINK LINES / FLOOR / SECONDARY DRAINS

3/4" to 4" (19 mm to 102 mm)

240 RPM

1/10 HP

Induction

3⁄8" or 1⁄2" Cable (10 or 13 mm)

50' - 75' - 100' (15 m - 23 m - 30 m)

Inner Core (IC), Integral Wound
(IW), Hollow Core (HC)

K-7500

LATERALS & MAIN LINES

3" to 10" (76 mm to 254 mm)

200 PRM

1/2 HP

Induction

5⁄8" or 3/4" Cable (16 or 19 mm)

25' - 50' - 75' - 100' (7.6 m - 15 m - 23 m - 30 m)

Heavy-Duty Inner Core (HD),
Inner Core (IC), Hollow Core (HC)

Model

Application Chart

Pipe / Drain Size

Speed

Hose power

Cable Diameter

Available Length

Cable Type

K-5208

K-60SP

K-50

SINK LINES / FLOOR / SECONDARY DRAINS

FLOOR / SECONDARY DRAINS

LATERALS & MAIN LINES

SINK LINES / FLOOR / SECONDARY DRAINS

2" to 8" (51 - 203 mm)

1-1⁄4" to 4" (32 - 102 mm)

3⁄4" to 4" (19 - 102 mm)

700 RPM

600 RPM

400 RPM

1/6 HP

1/2 HP

3/4 HP

7⁄8", 1-1⁄4" (22 mm, 32mm)

5⁄8", 7⁄8" () 16mm, 22 mm

5/16", 3/8", 5⁄8" () 8mm, 10mm, 16mm)

15' (4.6 m)

7-1⁄2', 10', 15' (2 m, 3 m, 4.6 m)

7-1⁄2', 10' (2 m, 3 m)

Tight Wound, All-Purpose Wound,
Heavy-Duty Wound

Tight Wound, All-Purpose Wound,
Heavy-Duty Wound, Plastic Core

All-Purpose Wound, Plastic Core, Extra Heavy-Duty Wound,
Heavy-Duty Wound, Extra Flexibility

Model

Application Chart

Pipe / Drain Size

Speed

Hose power

Cable Diameter

Available Length

Cable Type

K-1500 A/B

FLOOR / SECONDARY DRAINS

LATERALS & MAIN LINES

2" to 8" (51 - 203 mm)

710 RPM

3/4 HP

7⁄8", 1-1⁄4" (22 mm, 32mm)

15' (4.6 m)

All-Purpose Wound, Plastic Core, Extra Heavy-Duty Wound,
Heavy-Duty Wound, Extra Flexibility

K-1500SP

FLOOR / SECONDARY DRAINS

LATERALS & MAIN LINES

2" to 10" (51 - 254 mm)

600 RPM

1 HP

7⁄8", 1-1⁄4" (22 mm, 32mm)

15' (4.6 m)

All-Purpose Wound, Plastic Core, Extra Heavy-Duty Wound,
Heavy-Duty Wound, Extra Flexibility

Flexshaft

Model

K9-102

K9-204

K9-306

Line Size

Cable Size

1-1⁄4" to 2" (32 mm to 51 mm)

2" to 4" (51 mm to 102 mm)

3" to 6" (80 to 152 mm)

1⁄4" × 50' (6 mm x 15 m)

5⁄16" × 70' (8 mm x 21 m)

3/8" x 125' (10 mm x 38 m)

Water Jetter

Model

Line Size

Maximum Pressure

Flow

Horse Power

KJ-1590 II

KJ-3100

KJ-5000

1-1⁄4" to 6" (32 to 150 mm)

2" to 10" (51 to 254 mm)

2" to 10" (50 to 250 mm)

1160 PSI (80 Bar)

3000 PSI (206 Bar)

5075 PSI (350 Bar)

4 GPM (15.0 LPM)

5.5 GPM (20.8 LPM)

6.07 GPM (23 LPM)

Electricity 230V

Gasoline (Petrol) Engine

2.2 kW motor

16 HP (11931 W)

Net Power 16.5 kW (22.1 HP) / 3 600 rpm

Drain & Sewer Video Inspection

Hand-Held Video Inspection

micro CA-350 Inspection Camera

Inspection and documentation made easy with the RIDGID micro CA-350 Inspection Camera, now with 12V power.

Easily records still images and videos for job reporting
Ability to extend reach up to 100’ with small diameter SeeSnake® reels (microReel™, nanoReel®, microDRAIN®)
12V rechargeable Lithium-ion battery provides longer runtime for extended inspections
Includes a durable blow-molded case for protective storage and transportation
Interchangeable camera heads for smaller spaces and longer reaches

micro CA-150 Inspection Camera

The RIDGID® micro CA-150 Inspection Camera allows you to perform more detailed visual inspections in even harder-to-reach areas. Capture up to 20 still images during inspections to playback on screen later. Illuminate dark spaces with adjustable LEDs on the waterproof camera head. Interchangeable camera heads for smaller spaces and longer reaches

Capture up to 20 still images during inspections to playback on screen later
Large 3.5" color display allows fast diagnosis in tight hidden spaces
Includes a durable blow-molded case for protective storage and transportation
Illuminate dark spaces with adjustable LEDs on the waterproof camera head
Interchangeable camera heads for smaller spaces and longer reaches

micro CA-350 Inspection Camera

The micro CA-25 features a 17 mm aluminum imager head with 4 ultra-bright LED lights, bringing superior image quality to its 2.7” Color LCD Screen. It also features Video Out for transferring live images to external devices and 180° Digital Image Rotation for getting upright images. Included with the micro CA-25 in a hard shell plastic case are a hook, magnet, mirror and RCA cable.

View only monitor with 2.7” screen and 4’ long fixed imager
Includes a durable blow-molded case for protective storage and transportation
Illuminate dark spaces with adjustable LEDs on the waterproof camera head
Rotate images 180° for better viewing options
Comfortable overmold grip design with easy to use interface

Monitors & Recorders

CS6x VERSA Digital Reporting Monitor with Wi-Fi

CS6x Versa has high and low monitor mounting positions and a unique pivoting frame that lets users tilt the monitor to the desired angle for optimal viewing efficiency. This design allows the sunshade to remain open in all usage situations for maximum glare reduction. Docks to the Compact 2/C40/M40 camera reels for efficient transport, storage, and operation.

CS6xPak Digital Recording Monitor with Wi-Fi

Stream and/or record inspections to the latest iOS or Android devices. Enabling fast, efficient results.

Improving jobsite ergonomics, the CS6x Versa has high and low monitor mounting positions and a unique pivoting frame that lets users tilt the monitor to the desired angle for optimal viewing efficiency. This design allows the sunshade to remain open in all usage situations for maximum glare reduction.
The CS6x Versa has a 5.7” daylight viewable screen, direct USB recording, full TruSense® compatibility, and Wi-Fi connectivity for remote viewing and recording on a phone or tablet.
The frame docks to the Compact 2/C40/M40 and can be used mounted or unmounted.
Pivoting frame with high and low mounting positions allow flexible placement and optimal viewing
Docks to the Compact 2/C40/M40 camera reels for efficient transport, storage, and operation
Operates on one 18 V battery or with the included AC power adapter
Improved ingress protection against dust and moisture

Wi-Fi - Stream or record inspections to an iOS or Android phone or tablet with the free HQx Live companion app.
Storage Option - Capture images and video directly to a USB drive.
Water-resistant keypad - Direct control of camera and monitor functions
Transport and Storage - The CS6xPak docks onto the SeeSnake Compact2 and quickly detaches for convenient placement.
Daylight Viewable Display - Provides a crisp, clear, in-pipe image

CS6xPak Digital Recording Monitor with Wi-Fi

The RIDGID® SeeSnake® CS65XR is a powerful, all-in-one reporting solution for plumbing diagnostics. Built on the time-tested platform of the SeeSnake CS65x monitor, the CS65XR boasts a crisp, 1024 × 768 XGA high resolution and daylight viewable display for exceptional viewing on the jobsite.

Wi-Fi - Stream or record inspections to an iOS or Android phone or tablet with the free HQx Live companion app.
Storage Option - Capture images and video directly to a USB drive.
Water-resistant keypad - Direct control of camera and monitor functions
Transport and Storage - The CS6xPak docks onto the SeeSnake Compact2 and quickly detaches for convenient placement.
Daylight Viewable Display - Provides a crisp, clear, in-pipe image

Reels & Cameras

Pipe Wrenches & Tongs

C-Style Closed Quarters Copper Tubing Cutters

Cuts Copper Tubings

Tubing Size 1/2", 3/4" & 1"

Closed Quarters Tubing Cutters

Cuts Copper, Aluminum,
Brass & Plastic Tubing

Tubing Size 1/4" to 1-1/8" (6 to 28 mm)

2-in-1 Closed Quarters

AUTIFEED Cutters

Cuts Copper, Aluminum,
Brass & Plastic Tubing

Tubing Size 1/4" to 1-1/8" (6 to 28 mm)

Constant Swing Tubing Cutters

Cuts Copper, Aluminum,
Brass & Thin Wall Conduit

Tubing Size 1/8" to 1-3/8" (3 to 35 mm)

Enclosed Feed Tubing Cutter

Cuts Hard/Soft Copper, Aluminum, Brass & Multilayer Tubes

Tubing Size 1/4" to 2-3/8" (6 to 60 mm)

Quick-Acting
Tubing Cutters

Cuts Copper, Aluminum & Brass Tubings

Tubing Size
1/4" to 6-5/8" (3 to 170 mm)

Stainless Steel Duty Tubing Cutters

Cuts Stainless Steel Tubings

Tubing Size
3/16" to 2-5/8" (5 to 67 mm)

Plastic Pipe Cutters

Cuts Plastic
(PVC, CPYV, PP, PEX, PE, Rubber Hose) & Multilayer Tubings

Tubing Size
1/8" to 2-3/8" (3 to 63 mm)

Screw Feed
Tubing Cutters

Cuts Copper, Aluminum & Brass & Thin-Wall Conduits

Tubing Size
1/8" to 3-1/8" (3 to 79 mm)

Internal
Tubing Cutters

Cuts PVC or ABS Plastic

Tubing Size
2" to 4" (32 to 100 mm)

Pipe Wrenches & Tongs

Inner-Outer Reamer
127 /127S

I.D. Reaming and O.D. Beveling
Copper, Aluminum, Brass and Other Types of Tubing

1/8" to 1-1/2"
(3 mm to 40 mm)

Tube Expander
Model S

Single Stage Expander for Copper, Aluminum and Soft Steel Tube

3/8" to 1-3/4"
(8 mm to 54 mm)

Inner-Outer Reamer
223S / 227S

Inner Reaming and Outer
Deburring/ Beveling
Copper & Stainless Steel Tubing

1/4" to 2"
(6 mm to 50 mm)

Swaging Tools

Copper, Aluminum
or Brass Tubing

1/4" to 5/8"
(6 mm to 16 mm)

Deburring Tools
72 / 73 / 74

Removing Outside Ridges and inside Burrs on Plastic Pipe and Tubing

1/2" to 4"
(12 mm to 100 mm)

Tube Bender

300 Series
Plumbing Benders

Bend K&L Copper Tubing

5/8", 3/4"
(10, 12, 14, 15, 16 & 18 mm)

Model 456
Tri-Bender

Plumbing & HVAC Application

1/4", 5/16" & 3/8"

400 Series
Instrument Benders

Bends Anneal Copper, Steel & Stainless (Thickness ≤ 1.5mm)

3/16", 1/4", 5/16", 3/8" & 1/2"
(6, 8, 10 & 12 mm)

600 Series
Heavy-Duty Instrument Benders

Bends Stainless Steel & Titanium

3/16", 1/4", 5/16", 3/8" & 1/2"(6, 8, 10 & 12 mm)

Gear Ratchet
Tube Benders

Heavy Wall Steel (up to 1/8" Wall)
SS (up to 3/32" Wall Thickness)

5/8", 3/4" & 7/8"
(16, 19 & 22 mm)

Tube Flaring Tools

Precision Non-Ratchet
Flare Tools

Flare hard Copper, Steel, Stainless Steel and Brass thru wWall Thickness of 0.035"

3/16" to 3/4" (4mm to 16 mm )
37° SAE & 45° SAE Flares

Hammer-Type
Flating Tools

Long Nose Guide that Centers Tools for Smooth, 45° Uniform Flares.

3/8" to 2" (9 mm to 50 mm)
45° Uniform Flares.

Cutting & Pre Machine
122, 122XL, PC116

1/2" to 4"
(12 mm to 108 mm)

K, L, M Copper & Stainless Steel Wall Thickness up to 1.65 mm

Precision Ratcheting
Flare Tools

Flares Steel, Stainless Steel, Hard Copper and Brass Tubing - through a Wall Thickness of 0.035"

1/8" to 3/4"
45° SAE & 45° R410A Flares

Pressure Test Pump
1450 (Manual Operated)

Plastic Container, 13.5 L Capacity (Water, Oil, Ethylene Glycol).

Volume / Stroke
38 cm3

Electric Soldering Gun
RT-175

Soft Solders
1/4" to 3" Copper Tube

Flameless Soldering
Easy to Use

345 Manual
Flare Tools

Flares in Soft Copper, Brass, Aluminum and Mild Steel Tubing

3/16" to 5/8"
45° SAE Flares

Heavy Duty
Flare Tools

Flares Steel, Stainless Steel, Hard Copper and Brass.

1/2" to 1"
37° SAE, 45° SAE Flares

Pressure Test Pump
1460-E (Electric Operated)

SuperFreeze
SF-2500

Stainless Steel Container
(Non Acid Liquids)

Copper Tube (22, 28, 35, 42 mm)
Steel 1/2"(15 mm) to 2" (50 mm)

Water Flow
9 LPM

Compressor: Rotary, 230V, 50 Hz, 2.4A, 505W. (R-507)

Gate Valves

Velan Cast Steel (Bolted Bonnet) Gate Valves

Size Range

NPS 2 – 64

(DN 50 - 1600)

Pressure Rating

ASME Classes

150 - 1500

Standard Connections

Lug, Double flanged (short and long) pattern, Butt weld

Features and Benefits

Universal trim: 13Cr stem, wedge in CA 15 or 13Cr faced, and CoCr alloy faced seat API Trim 8 suitable for applications up to 850°F (454°C).

Seat face CoCr alloy hardfaced, ground and lapped to a mirror finish.

Flexible wedge with low center stem-wedge contact, in solid CA15 (13Cr) or hardfaced with 13Cr, SS 316, Monel or CoCr alloy. Wedge is ground and lapped to a mirror finish and tightly guided to prevent dragging and seat damage.

A CoCr alloy hardfaced CF8M wedge is also available.

Non-rotating stem with precision Acme threads and burnished finish. Double Acme for faster operation.

Body and bonnet joint accurately machined.

Body and bonnet castings are precision machined.

One-piece bonnet for better alignment and fewer parts for Class 150 up to NPS 16 (DN 400).

Flanges:

ASME Classes: 150–300: 1⁄16” raised face

ASME Classes: 600–1500: ¼” raised face

Finish: 125–250 AARH for all valves.

Rotating stem nut is Austenitic ductile iron Gr. D-2C renewable in line (as shown).

When handwheel is used, thrust bearings are supplied as follows:

ASME Classes 150–300: NPS 10–12 (DN 250–300), 1 bearing (top)

NPS 14 (DN 350) and up, two bearings

ASME Classes 600–1500: NPS 6 (DN 150) and up.

Velan Cast Steel Hydrofluoric (HF) Acid Alkylation Gate Valves

Features and Benefits

Packing chamber has nickel overlay to protect from severe alkylation conditions and to guarantee low fugitive emissions.

Stem is made from solid age hardened K-Monel® 500 for increased strength and corrosion resistance.

All of the critical areas of castings are of RT quality in accordance to B16.34.

Bonnet joint is precision machined and has a special surface finish for extended service life.

Monel® seats are single seal welded-in using state-of-the-art metallurgical technology to ensure zero leakage behind and around the seats, preventing in-service corrosion

Fully encapsulated gasket design with metal-to-metal body to bonnet contact for optimal and controlled gasket compression.

Body/bonnet wall thickness is in accordance to higher limits of API 600 offering one of the highest corrosion resistance capacities in the market.

HF acid detecting paint allows for an immediate visual detection when exposed to acid or acid vapors to ensure valve integrity

Fugitive emissions qualified to API 624 and ISO 15848-1

Flexible round wedge pioneered by Velan assures valve tightness and compensates for seat distortion and body deformation.

Size Range

NPS 2 – 64

(DN 50 - 900)

Pressure Rating

ASME Classes

150, 300, and 600

Standard Connections

Flanges

Velan Small Forged Steel Gate Valves

Size Range

NPS 1/4 - 2

(DN 8 -50)

Pressure Rating

ASME Classes

150 - 1500

Standard Connections

Threaded, Socket Weld, Flanged

Features and Benefits

Complies to API 602 and ASME B16.34 standards.

A compact but extremely sturdy design for high pressure-temperature service.

Available with bolted or welded bonnet.

Meets API 624 and ISO 15848-1 fugitive emissions standards.

Packing rings are pre-compressed in the packing chamber to ensure equal stress distribution, effectiveness of all rings and a high integrity seal.

For welded bonnet valves, the bonnet is threaded in and torqued to an engineered torque value and the body bonnet joint is strength-welded, offering double protection against leakage. (body/bonnet threads and strength-weld).

CoCr alloy hardfaced wedge (optional) ensures low friction and long service life.

Fully guided wedge reduces wear on seating surfaces.

For Class 1500 valves and for steam service, seats are seal-welded to the body.

Repairable two-piece stem drive.

Pre-positioned field injection ports for precise application of low emissions (Low-E) injectable packing through the bonnet (applies to bolted bonnet gate NPS 1/4–2 (DN 8–50) Class 150–1500).

Optional designs available with double packing, leak-off connection, live-loading, and packing blowout for easy removal of old packing.

Velan Forged Steel Hydrofluoric (HF) Acid Alkylation Gate Valves

Size Range

NPS 1/2 -2

(DN 15 -50)

Pressure Rating

ASME Classes

150 - 800

Standard Connections

Threaded, Socket Weld, Flanged, Butt Weld

Features and Benefits

Fugitive emissions are a critical factorin the performance of any HF Acid valve and at Velan, we have been committed to reducing emissions beyond the industry standards, and providing the highest quality products to our customers for over 50 years. Velan offers a comprehensive line of Phillips and UOP approved API 602 gate, globe and check HF acid valves with several benefits.

Packing chamber has nickel overlay to protect from severe alkylation conditions and to guarantee low fugitive emissions.

Stem is made from solid age hardened K-Monel® 500 for increased strength and corrosion resistance.

Bonnet joint is precision machined and has a special surface finish for extended service life.

Fully encapsulated gasket design with metal-to-metal body to bonnet contact for optimal and controlled gasket compression.

Body/bonnet threads and strength-weld: for welded bonnet valves, the bonnet is threaded-in and torqued to an engineered torque value and the body bonnet joint is strength-welded, offering double protection against leakage.

Repairable two-piece stem drive.

API 602 conventional port and full port designs available.

Wide variety of end connections as per client’s needs: flanged, BW, SW, NPT, weld stubs, including other types.

HF acid detecting paint allows for an immediate visual detection when exposed to acid or acid vapors to ensure valve integrity.

Fugitive emissions qualified to API 624 and ISO 15848-1.

Globe Valves

Velan Cast Steel (Bolted Bonnet) Globe Valves

Size Range

NPS 2 - 24

(DN 50 - 600)

Pressure Rating

ASME Classes

150 - 1500

Standard Connections

Flanged

Features and Benefits

Unique non-rotating stem design is easily adaptable for actuation – with precision Acme threads and burnished finish. Valve suitable for horizontal installation.

Universal trim: 13Cr stem, 13Cr faced disc, and CoCr alloy faced seats – API Trim 8 suitable for service up to 850°F (454°C).

Seat face CoCr alloy hardfaced, ground, and lapped to a mirror finish. Conical seat machined to fine surface finish.

Body guided disc accurately mates the hardfaced surface of the disc (hardfaced with 13Cr, CoCr alloy, SS 316, or Monel) with the surface of the body seat, which is ground and lapped to a mirror finish.The disc guides are hardfaced to extend the wear life of the disc guides.

Body and bonnet castings are precision machined. One-piece bonnet for better alignment, fewer parts.

Stuffing box machined to fine surface finish.

Body and bonnet joint accurately machined to fine surface finish. Fully enclosed gasket.

Gland has two-piece construction for easy alignment.

Rotating stem nut in Austenitic ductile iron Gr. D-2C, renewable in-line.

Torque arm reduces wear on packing rings and enables better sealing and reduces torque.

Impactor handwheels: Globe and stop check valves require higher closing torques than gate valves with the same seat diameter and pressure class. The most economical mechanism for tight shutoff is the impactor handwheel. Two lugs cast under the wheel strike simultaneous blows and give 3–10 times the closing force of standard handwheels. Impactor handwheels are supplied at manufacturer’s option unless specified by customer.

Flanges: ASME Classes: 150–300: 1⁄16” raised face.

ASME Classes: 600–1500: ¼” raised face.

Finish: 125–250 AARH for all valves..

Velan Cast Steel Hydrofluoric (HF) Acid Alkylation Globe Valves

Size Range

NPS 2 - 23

(DN 50 - 900)

Pressure Rating

ASME Classes

150, 300, and 600

Standard Connections

Flanged

Features and Benefits

Packing chamber has nickel overlay to protect from severe alkylation conditions and to guarantee low fugitive emissions.

Stem is made from solid age hardened K-Monel® 500 for increased strength and corrosion resistance.

All of the critical areas of castings are of RT quality in accordance to B16.34

Bonnet joint is precision machined and has a special surface finish for extended service life.

Monel® seat is single seal welded-in using state-of-the-art metallurgical technology to ensure zero leakage behind and around the seat, preventing in-service corrosion.

Fully encapsulated gasket design with metal-to-metal body to bonnet contact for optimal and controlled gasket compression.

Body/bonnet wall thickness is in accordance to higher limits of API 600/623 offering one of the highest corrosion resistance capacities in the market.

HF acid detecting paint allows for an immediate visual detection when exposed to acid or acid vapors to ensure valve integrity

Fugitive emissions qualified to API 624 and ISO 15848-1.

Unique non-rotating stem design is easily adaptable for actuation – with precision Acme threads and burnished finish. Valve suitable for horizontal installation.

Body guided disc accurately mates solid Monel® 400 surface of the disc with the surface of the body seat, which is ground and lapped to a mirror finish.

Optimised sealing angle between a conical seat and the disc, increasing pressure contact up to 5 times compared with flat seats design.

Velan Small Forged Steel Globe Valves

Size Range

NPS 1/4 - 2

(DN 8 - 50)

Pressure Rating

ASME Classes

150 - 1500

Standard Connections

Threaded, Socket Weld, Flanged

Features and Benefits

Complies to API 602 and ASME B16.34 standards.

A compact but extremely sturdy design for high pressure-temperature service.

Available with bolted or welded bonnet.

Meets API 624 and ISO 15848-1 fugitive emissions standards.

Packing rings are pre-compressed in the packing chamber to ensure equal stress distribution, effectiveness of all rings and a high integrity seal.

CoCr alloy hardfaced disc (optional) ensures low friction and long service life.

Body guided disc eliminates side thrust and provides longer disc, seat, and body life.

Pre-positioned field injection ports for precise application of low emissions (Low-E) injectable packing through the bonnet (applies to bolted bonnet globe NPS 1/4–2 (DN 8–50) Class 150–1500).

Available disc designs: stop, stop check, needle, and flow control.

Optional designs available with double packing, leak-off connection, and live-loading.

Velan Forged Steel Hydrofluoric (HF) Acid Alkylation Globe Valves

Size Range

NPS 1/2 -2

(DN 15 - 50)

Pressure Rating

ASME Classes

150 - 800

Standard Connections

Threaded, Socket Weld, Flanged, Butt Weld

Features and Benefits

Packing chamber has nickel overlay to protect from severe alkylation conditions and to guarantee low fugitive emissions.

Stem is made from solid age hardened K-Monel® 500 for increased strength and corrosion resistance.

Bonnet joint is precision machined and has a special surface finish for extended service life.

Fully encapsulated gasket design with metal-to-metal body to bonnet contact for optimal and controlled gasket compression.

Fully guided wedge reduces wear on seating surfaces.

Repairable two-piece stem drive.

API 602 conventional port and full port designs available.

Standard stop globe design. Needle and flow control designs available upon request.

Wide variety of end connections as per client’s needs: flanged, BW, SW, NPT, weld stubs, including other types.

Optimised sealing angle between a conical seat and the disc, increasing pressure contact up to five times compared with flat seats design.

Body guided disc accurately mates solid Monel® 400 surface of the disc with the surface of the body seat, which is ground and lapped to a mirror finish.

HF Acid detecting paint -allows for an immediate visual detection when exposed to acid or acid vapors to ensure valve integrity.

Fugitive emissions qualified to API 624 and ISO 15848-1.

Velan Forged Steel Bonnetless Y-Pattern Globe Valves

Size Range

NPS 1/4 - 4

(DN 8 - 100)

Pressure Rating

ASME Classes

1690 - 4500

Standard Connections

Socket Weld, Butt Weld, and Threaded

Features and Benefits

Designed for quick and easy maintenance – one step removal of all working parts including packing.

All pressure containing parts within one body-bonnet forging – no joints to leak or welds to cut for servicing.

Non rotating stem allows a non-spinning disc, ensures low torque and prevents torsional damage of the packing.

Fully enclosed, lubricated stem drive system with needle bearings ensures low operating torque.

Solid CoCr alloy disc, seat ring and backseat provide excellent long service life even in severe services.

Backseat bevel on the stem, not on the disc, satisfies both API-600 and API-602 specifications.

Optional live-loading: keeps packing tight for long periods of time without maintenance.

Optional double packing and leak-off.

Check Valves

Velan Cast Steel (Bolted Bonnet) Swing Check Valves

Size Range

NPS 2 - 48

(DN 50 - 1200)

Pressure Rating

ASME Classes

150 - 1500

Standard Connections

Flanged

Features and Benefits

Body and cover: Precision machined castings.

Exclusive: Disc shaft does not penetrate body.

Body and cover joint: Accurately machined,

fully-enclosed gasket.

Disc: Robust one-piece construction to withstand the severe shock of check valve service. Hardfaced with 13Cr, CoCr alloy, SS 316, or Monel, ground and lapped to a mirror finish. Sizes NPS 2–6 (DN 50–150) may have solid CA 15 (13Cr) disc. SS 316 disc with CoCr alloy facing also available.

Disc assembly: Non-rotating disc is fastened securely to disc hanger with a lock nut and cotter pin. Disc hanger is supported on a sturdy disc carrier hinge pin of excellent bearing qualities. All parts are accessible from top for easy servicing.

Flanges:

ASME Classes 150–300: 1⁄16” raised face.

ASME Classes 600–1500: 1⁄4” raised face.

Finish 125–250 AARH for all valves.

Velan Cast Steel Hydrofluoric (HF) Acid Alkylation Swing Check Valves

Size Range

NPS 2 - 36

(DN 50 - 900)

Pressure Rating

ASME Classes

150, 300, and 600

Standard Connections

Flanged

Features and Benefits

All of the critical areas of castings are of RT quality in accordance to B16.34

Bonnet joint is precision machined and has a special surface finish for extended service life.

Monel® seat is single seal welded-in using state-of-the-art metallurgical technology to ensure zero leakage behind and around the seat, preventing in-service corrosion.

Fully encapsulated gasket design with metal-to-metal body to bonnet contact for optimal and controlled gasket compression.

Body wall thickness is in accordance to higher limits of API 600/594 offering one of the highest corrosion resistance capacities in the market.

HF Acid detecting paint allows for an immediate visual detection when exposed to acid or acid vapors to ensure valve integrity

Non-rotating disc is fastened securely to disc hanger with a lock nut and cotter pin. All parts are accessible from top for easy servicing.

Cage unit design with no body penetration by hinge pin.

For greater sizes (6’’ and above) top lid is delivered with 2 extended studs for easy handling and valve maneuver.

Velan Small Forged Steel Check Valves

Features and Benefits

Check valves are installed to allow flow in one direction only and they protect systems that can be affected by reverse flow, such as a system shutdown. They are operated entirely by reaction to the flow and therefore do not require external actuation. Care and attention should be paid to check valve installation orientation.

Velan small forged steel check valves comply to API 602 and ASME B16.34 standards.

A compact but extremely sturdy design for high pressure-temperature service.

Quick and easy repair in the line.

Available types: Piston, ball, swing check

Size Range

NPS 1/4 - 2

(DN 8 - 50)

Pressure Rating

ASME Classes

150 - 1500

Standard Connections

Threaded, Socket Weld, Flanged

Velan Cast Steel Hydrofluoric (HF) Acid Alkylation Swing Check Valves

Size Range

NPS 1/2 - 2

(DN 15 - 50)

Pressure Rating

ASME Classes

150 - 800

Standard Connections

Threaded, Socket Weld, Flanged, Butt Weld

Features and Benefits

Available designs: spring actuated piston and ball, and swing check.

Bonnet joint is precision machined and has a special surface finish for extended service life.

Fully encapsulated gasket design with metal-to-metal body to bonnet contact for optimal and controlled gasket compression.

Wide variety of end connections as per client’s needs: flanged, BW, SW, NPT, weld stubs, including other types.

Swing check non-rotating disc is fastened securely to disc hanger with a lock nut and cotter pin. All parts are accessible from top for easy servicing.

Cage unit design with no body penetration by hinge pin.

HF acid detecting paint allows for an immediate visual detection when exposed to acid or acid vapors to ensure valve integrity.

Velan Proquip Dual-Plate Check Valves: Wafer Type

Size Range

NPS 2 - 60

(DN 50 - 1500)

Pressure Rating

ASME Classes

150 - 2500

Standard Connections

Wafer

Features and Benefits

Retainerless emission-free design. With no holes through the body wall, leakage to the outside is impossible.

Body surface with uninterrupted gasket surface.

Intrinsically fire safe.

The reduced weight of the disc minimises slamming and water hammer.

The disc side hinges, eliminate the effect of gravity resulting in lower energy costs when installed in a horizontal pipeline.

Design maximises the flow path area through the valve with a lower pressure drop. The internal retention method does not encroach on the gasket sealing surface.

Springs provide a fast-acting response to flow reversal, minimising stress and maximising service life.

Shock bumpers extended cycle life of internal components with minimal wear in severe service.

Extended seat life due to the clearance between the disc hinge and hinge pin which eliminates any dragging effect from the discs.

Velan Proquip dual plate check valves easily meet and exceed test requirements of API 598 for metal-seated check valves.

API 594 Face-to-face dimension

To suit ANSI B16.5 flanges, NPS 2-24 (DN 50-600)

To suit ANSI B16.47 Series A flanges, NPS 26 (DN 650) and larger

ASME B16.47 Series B available upon request..

Velan Proquip Dual-Plate Check Valves: Double Flange Type

Size Range

NPS 12 - 60

(DN 300 - 1500)

Pressure Rating

ASME Classes

150 - 900

Standard Connections

Flanged

Features and Benefits

Velan Proquip double flange dual-plate check valves are made of cast carbon, stainless, or alloy steel to handle an extensive range of applications. The retainerless body is available in a drilled-thru or threaded double flange ends.

Retainerless emission-free design. With no holes through the body wall, leakage to the outside is impossible.

Body surface with uninterrupted gasket surface.

Intrinsically fire safe.

The reduced weight of the disc minimises slamming and water hammer.

The disc side hinges, eliminate the effect of gravity resulting in lower energy costs when installed in a horizontal pipeline.

Design maximises the flow path area through the valve with a lower pressure drop. The internal retention method does not encroach on the gasket sealing surface.

Springs provide a fast-acting response to flow reversal, minimising stress and maximising service life.

Shock bumpers extended cycle life of internal components with minimal wear in severe service.

Extended seat life due to the clearance between the disc hinge and hinge pin which eliminates any dragging effect from the discs.

Velan Proquip dual plate check valves easily meet and exceed test requirements of API 598 for metal-seated check valves.

ASME B16.5 for NPS 12–24 (DN 300–600)

ASME B16.47 Series A for NPS 26 (DN 650) and larger

ASME B16.47 Series B available upon request

Ball Valves

Velan Securaseal SB-150/300/600 Resilient-Seated Ball Valves

Size Range

NPS 2 - 24

(DN 50 - 600)

Pressure Rating

ASME Classes

150 - 600

Standard Connections

Flanged

Features and Benefits

Off-center split-body design allows the use of advanced spiral-wound gaskets.

Maximum temperature for CF8M 1,000°F (538°C), for WCB 800°F (426°C).

Full port ensures large capacity and reduces the risk of clogging when handling solids or slurries.

Valve/packing meets ISO and API Fugitive Emissions Standards, and corrosion test requirements.

Wall thickness complies with ASME B16.34 and BS 5351 for NPS 2–12 (DN 50-300) ASME 150 and 300 full port only.

Stem bearing reduces side thrust effect on packing and prevents stem wobbling.

Integral seat locking option does not require additional parts or special tools.

Scraper seats standard.

Ball and seats lapped for optimum performance and tight shutoff.

Low emission stem seal.

Blowout-proof stem.

Two-piece flanged gland. Live-loaded as standard.

All valves with graphite packing and backup seal are inherently fire safe.

Can be used for manual throttling applications. (For automation contact Velan Engineering.)

Manual operation with handle for NPS 2–4 (DN 50 –100) FP and NPS 3–6 (DN 80–150) RP. 6 NPS (DN 150) FP, NPS 8 (DN 200) RP and larger require gear or actuator. Gear or pneumatic actuator available.

Tightness rates: Allowable leakage rate at full ΔP: ASME/FCI 70-2 Class V. Tighter shutoff available upon request.

Oversized ball to stem connection provides: no deformation of the stem slot in the ball; better throttling control performance; and less motion loss and wear in automatic on-off applications.

Velan Securaseal TE-150/300/600 Resilient-Seated Ball Valves

Size Range

NPS 1/2 - 6

(DN 15 - 150)

Pressure Rating

ASME Classes

150 - 600

Standard Connections

Threaded, Socket weld, Butt Weld, Flanged

Features and Benefits

The Velan top-entry metal-seated ball valve is one of the most universally used valves on the market today. As a standard design it is ideally suited for manual, automatic and throttling control for a wide range of applications for pressure up to 1,480 psig (102 bar) and temperatures up to 1,000°F (538°C) depending upon size, metallurgy and end connections.

Permits in-line access for seat replacement.

Can be welded into line without disassembly. Consult IOM for details.

Full port reduces risk of clogging in slurries and solids applications.

Body-cover joint not affected by pipe stresses.

High sealing integrity of body-cover joint due to fully-enclosed spiral-wound stainless steel graphite gasket design.

Solid CoCr alloy seats with large seating faces.

Backup seal: Graphite to 1,000°F (538°C).

Operation automatically wipes ball clean.

Wall thickness complies with ASME B16.34.

Stainless steel ball, hard chrome plated.

Stainless steel blowout-proof stem.

Low emission stem seal.

Live-loaded two-piece flanged gland.

Fully-guided stem reduces side thrust effect to eliminate wobbling.

Heavy stainless handle for manual operation. Up to NPS 2 (DN 50) for regular port. (For automation contact Velan Engineering.)

Oval handles and extension handles available.

Tightness rates: Allowable leakage rate at full ΔP: ASME/FCI 70-2 Class V. Tighter shutoff available upon request.

Velan Memoryseal UB-150/300 Resilient-Seated Ball Valves

Size Range

NPS 1/2 - 12

(DN 15 - 300)

Pressure Rating

ASME Classes

150, 300

Standard Connections

Flanged

Features and Benefits

Velan Memoryseal unibody resilient-seated ball valves are designed with unique 3-way packing arrangements for superior stem sealing to handle an extensive range of applications. These rugged, versatile, and high-performance unibody Memoryseal resilient-seated ball valves meet NACE specifications

Exclusive Memoryseal seats compensate automatically for wear and fluctuations of pressure and temperature.

Unique 3-way packing arrangements for superior stem sealing.

Multiple solid cup and cone type PTFE stem seal and graphite packing.

Fully enclosed PTFE body seal.

Valve/packing meets ISO and API Fugitive Emissions Standards.

Long cycle life.

Low, uniform torques.

Blowout-proof stem with stem guides prevent side thrust.

Locking devices standard on lever operated valves.

Valves are fire safe per API 607 / ISO 10497.

Certified TA-Luft (optional).

Velan Proquip Dual-Plate Check Valves: Double Flange Type

Size Range

NPS 1/4 - 2

(DN 8 - 50)

Pressure Rating

Up to 2000 PSIG

Standard Connections

Threaded

Features and Benefits

Exclusive Memoryseal™ seats compensate automatically for wear and fluctuations in pressure and temperature.

Multiple solid cup and cone type PTFE stem seal or graphite packing.

Fire tested in accordance with API 607 Rev. 5/ISO 10497.

Adjustable self locking threaded gland NPS 1/2 – 2 (DN 15–50).

Stem guide in gland bushing prevents side thrust.

Long cycle life.

Low, uniform torques.

Blowout-proof stem.

Thrust washer prevents galling, reduces torque and provides secondary stem seal.

One-piece heavy wall body for high structural strength to ASME B16.34.

Full size packing chamber.

Protective metal washer for packing rings.

Stainless steel handle with safety clip. Oval handwheel also available.

Velan Valvac VOP-1000 One-Piece Ball Valves

Velan Valvac VEE-2000 End-Entry Ball Valves

Velan Valvac V3P-1000 Three-Piece Ball Valves

Features and Benefits

Carbon or stainless steel body materials.

RPTFE seats.

Size Range

NPS 1/4 - 2

(DN 8 - 50)

Pressure Rating

Up to 1000 PSIG

Standard Connections

Threaded

Features and Benefits

Carbon or stainless steel body materials.

RPTFE seats.

Size Range

NPS 1/4 - 2

(DN 8 - 50)

Pressure Rating

Up to 2000 PSIG

Standard Connections

Threaded

Features and Benefits

The Velan Valvac three-piece ball valve with integral ISO mounting pad is a low-cost ball valve for many industrial, commercial and OEM automated applications. The ISO mounting pad will allow quick and easy direct mounting of ISO compatible quarter-turn actuators. A key feature of this valve is the ability to easily adjust the packing without the removal of the actuator.

Multiple solid cup and cone type PTFE packing-adjustable.

Thrust washer prevents galling, reduces torque and provides secondary stem seal.

Adjustable packing with self-locking gland nut complete with protective metal packing washer.

4-bolt bracket to ISO standard for automation.

Blowout-proof stem.

Threaded or socket weld ends.

Size Range

NPS 1/4 - 2

(DN 8 - 50)

Pressure Rating

Up to 1000 PSIG

Standard Connections

Threaded, Socket Weld

Velan Coker Four-Way Switch Ball Valves

Size Range

NPS 3 - 18

(DN 80 - 450)

Pressure Rating

ASME Classes

150 - 900

Standard Connections

Available

Features and Benefits

The sturdy one-piece ball and stem provides optimal strength, and is well suited to applications where fouling due to coke fines are a concern. The one-piece design avoids the problems generally associated with the more conventional two-piece ball and stem, which is highly susceptible to solids buildup in the ball-stem joint and a resulting increase in operating torques.Avoids hysteresis and misalignment.

A Lantern ring with steam block and extra deep stuffing box minimises the risk of leakage occurring through the packing chamber. Live-loading is available on request.

Strong bellows offer a unique seat loading design that maintains the floating seats in constant contact with the ball and ensures a positive seal.

Velan’s unique scraper type seats design scrapes coke buildup from the surface of the ball during each cycle. Seats are hard-faced to ensure a long, trouble-free service life.

Steam purges to bellows and body area ensure the valve cavities are kept free of coke buildup.

The stem coupling is designed to perform three main functions:

Protect against “overtorquing” of the stem.
Protect the actuator components.
Protect against an unintentional switch into bypass (typically applies to four-way switch).

AUTOMATION

The electric, hydraulic or pneumatic actuator is selected in function of coker service. A large torque safety factor ensures the valve will cycle under the most stringent conditions. When selecting actuators, special attention is paid to the coker deck environment.

Velan Coker Isolation Ball Valves

Size Range

NPS 2 - 36

(DN 50 - 900)

Pressure Rating

ASME Classes

150 - 900

Standard Connections

Available

Features and Benefits

Optimised for superior isolation–the right choice for uninterrupted service in delayed coking.

A Lantern ring with steam block and extra deep stuffing box minimises the risk of leakage occurring through the packing chamber. Live-loading is available on request.

Strong bellows offer a unique seat loading design that maintains the floating seats in constant contact with the ball and ensures a positive seal.

Velan’s unique scraper type seats design scrapes coke buildup from the surface of the ball during each cycle. Seats are hard-faced to ensure a long, trouble-free service life.

Steam purges to bellows and body area ensure the valve cavities are kept free of coke buildup.

The stem coupling is designed to perform three main functions:

Protect against “overtorquing” of the stem.

Protect the actuator components.

Protect against an unintentional switch into bypass (typically applies to four-way switch).

AUTOMATION

Velan Coker Ring Type Backpressure Control Ball Valves

Size Range

NPS 14 - 36

(DN 50 - 200)

Pressure Rating

ASME Classes

150 - 300

Standard Connections

Available

Features and Benefits

Patented Velan ring valves are an intrinsically safe design. The ring valve has no seats. It is a throttling valve. As a result, it does not require a mechanical stop in order to avoid full closure and the resulting drum over-pressurisation.

Steam purges: Steam purges to bellows and body area ensure the valve cavities are kept free of coke buildup.

Excellent throttling characteristics: In the “maximum obstruction” position, the valve provides a pressure drop equal to a butterfly valve’s set at 15° open.

Automation

Velan Coker High Pressure Hydrodrill Ball Valves

Features and Benefits

Velan Securaseal R-series full bore ball valves are generally installed in high pressure applications where the highly erosive and sometimes corrosive reclaimed waters, used to drill the coke out of the drum, can significantly shorten valve life.

In order to ensure long, leak-free, reliable operation all valve wetted parts are hardfaced.

Valves are available in A105 or low temperature steels with stainless steel internals.

Both uni-directional and bi-directional are available.

Automation

General supplied with pneumatic or electric actuations that can be integrated into an existing OEM Logic.

Size Range

NPS 1 1/2 - 12

(DN 40 - 300)

Pressure Rating

ASME Classes

1500 - 2500

Standard Connections

Available

Butterfly Valves

Velan Coker Four-Way Switch Ball Valves

Size Range

NPS 3 - 96

(DN 80 - 2400)

Pressure Rating

ASME Classes

150 - 600

Standard Connections

Lug, Double flanged (short and long) pattern, Butt weld

Features and Benefits

Velan’s Torqseal® 2.0 triple offset valve is engineered to deliver repeatable full bi-directional zero leakage, lower torques and superior fugitive emissions performance.

Offering a bi-directional zero leakage closure with a metal-to-metal seat, the Torqseal® triple offset valve is the right solution when a tight seal is required.

The Torqseal’s all metal construction results in an inherently fire-safe design that can stand up to the most demanding services.

The Torqseal® advanced design features a triple eccentricity and unique elliptical seat geometry, that allows for friction free, non-rubbing operation of the valve during all the valve travel.
Standard laminated resilient disc seal to 800°F (427°C). One to four graphite layers are carefully assembled between stainless steel rings using a phenolic resin bond. The self-adjusting, resilient seal flexes and energises, assuming the shape of the seat.
The Torqseal® triple offset valve’s conical cone-in-cone seating results in a non-rubbing and repeatable sealing and ensures little to no wear on the sealing components. The Torqseal® 2.0 uses triple offset geometry to ensure that the sealing ring contacts the body seat at the final shut-off position, without rubbing or galling. The Torqseal® 2.0 newly optimised fit-to-body offsets reduce operating torques requirements.
Zero leakage seat tightness (API 598 resilient seat standard). The resilient metal seal ring radially compresses around its circumference when torque is evenly applied as the seal ring makes contact with the integral metal body seat.
The robust centered-weighted splined connection(1) between disc/shaft produces a uniform and repeatable torque transmission and ensures even distribution of contact pressure between seat and seal.
Industry-leading emission control. With global emissions challenges facing the industry, Torqseal® triple offset valves are designed with the highest attention to controlling fugitive emissions, meeting API 641/ ISO FE standards.
